SAFEGATE SMPO 1653
Safety light curtain for hand detection with integrated muting function, automatic/manual restart and EDM, with muting lamp, adjustable functions

Betreff: SAFEGATE SMPO 1653 Safety light curtain for hand detection with integrated muting function, automatic/manual restart and EDM, with muting lamp, adjustable functions

General data

Item number
SP-R-13-902-90
Type designation
SAFEGATE SMPO 1653
Functional type
Safety light curtain for hand detection with integrated muting function, automatic/manual restart and EDM, with muting lamp, adjustable functions
Number of beams
83
Muting function
Integrated
Muting logic
T (Two way) Logic with 2 or 4 crossed sensors or parallel beams. L (One way) Logic with 2 crossed sensors or parallel beams.
Max. Override timeout
15 min.
Max. Muting timeout
30 sec. or 9 hours selectable - Infinite (only models with 4 sensors sequential muting logic)
Built-in muting lamp
Yes
Muting sensors
External with relay or PNP DARK-ON output, Muting arms kit, Muting brackets with M5 sensors kit
Signalling
LED display for diagnostics, light curtain status and muting sensor status
Detection
Hand
Programmability
Yes
