SAFEGATE SM 901
Safety light curtain for finger detection with integrated muting function, automatic/manual restart and EDM

Betreff: SAFEGATE SM 901 Safety light curtain for finger detection with integrated muting function, automatic/manual restart and EDM

General data

Item number
SP-R-13-900-25
Type designation
SAFEGATE SM 901
Functional type
Safety light curtain for finger detection with integrated muting function, automatic/manual restart and EDM
Number of beams
90
Muting function
Integrated
Muting logic
T (Two way) Logic with 2 or 4 crossed sensors or parallel beams. L (One way) Logic with 2 crossed sensors or parallel beams.
Max. Override timeout
15 min.
Max. Muting timeout
30 sec. or 9 hours selectable - Infinite (only models with 4 sensors sequential muting logic)
Built-in muting lamp
No
Muting sensors
External with relay or PNP DARK-ON output, muting arm kit, muting bracket kit with M5 sensors
Signalling
LED display for diagnostics, light curtain status and muting sensor status
Detection
Finger
